Small Cabin Forum / Member's Projects and Photos / Bunkie build in the north
. 1 . 2 . 3 . >>
Author Message
fitzpatt
Member
# Posted: 4 Oct 2013 09:02 - Edited by: fitzpatt
Reply


I have used this site and forum to get inspiration for my build and wanted to share my progress over three long weekend trips. My brother and I did a lot of the work, but also had girlfriends and daughters to help out. I am heading up this weekend to finish some of the finer details.
Deliverin
Deliverin
figurin
figurin


fitzpatt
Member
# Posted: 4 Oct 2013 09:03
Reply


more
insulatin
insulatin
framin
framin
typarin
typarin


fitzpatt
Member
# Posted: 4 Oct 2013 09:04
Reply


more


fitzpatt
Member
# Posted: 4 Oct 2013 09:05
Reply


more
Roofin
Roofin


Just
Member
# Posted: 4 Oct 2013 09:37
Reply


WOW,3 weeks, that's got to be a record, looks great.

countrygirl
Member
# Posted: 4 Oct 2013 10:22
Reply


Nice. look good out there, and so fast. Guess in inside is next.

basrijn
Member
# Posted: 4 Oct 2013 10:36
Reply


Hi,

Very cool build fitzpatt. How are the metal supports you have on top of the concrete pier called? Never seen those before.

Tx
Bas

fitzpatt
Member
# Posted: 4 Oct 2013 15:14
Reply


Thanks all.

Bas, the supports are called "adjustable supports for decks" and come in various sizes. They are great for small structures like this and are especially useful to correct for heaving and settlement in areas where the ground freezes in the winter. Adjustment is accomplished by way of turning the nut attached to the bolt under the metal piece that the PT lumber sits within. You can elect to drill these into a concrete block or simply set them into a deck block and let the weight of the structure keep them in place.

http://www.rona.ca/en/adjustable-support-44c-for-decks

leonk
Member
# Posted: 4 Oct 2013 18:01
Reply


very good looking bunkie.
where is it?

Sarg68
Member
# Posted: 4 Oct 2013 19:59
Reply


Great build Fitz! I too need some of those AS for decks. Shear genius they are. Look forward to seeing more pictures as time goes on. Enjoy it with your friends and family. Cheers Sarg68

SandyR
Member
# Posted: 5 Oct 2013 19:34
Reply


Glad to see you got it done before the colder weather comes in

fitzpatt
Member
# Posted: 7 Oct 2013 15:43
Reply


Thanks leonk, it is located in Hastings Highlands, Ontario. I went up this weekend and started on some much needed additional storage space.


fitzpatt
Member
# Posted: 7 Oct 2013 15:43
Reply


and one more


sweet75
Member
# Posted: 16 Oct 2014 10:26
Reply


Awesome! Love it!

Wilbour
Member
# Posted: 16 Oct 2014 10:39
Reply


This looks like the Bunkie plans from Tmbr lumber. I saw something like this online somewhere

Nice job!

fitzpatt
Member
# Posted: 16 Oct 2014 11:27
Reply


Thank you both. Yes, this bunkie was loosely based on the timber mart plan. I'm glad you came by this post. It made me realize that I haven't provided an update for some time. I have completed a number of other projects that I will post photos of below.

fitzpatt
Member
# Posted: 16 Oct 2014 12:50 - Edited by: fitzpatt
Reply


All stained


fitzpatt
Member
# Posted: 16 Oct 2014 12:53
Reply


all insulated. My wife was tired.


fitzpatt
Member
# Posted: 16 Oct 2014 12:54
Reply


second set of visitors on the porch.


fitzpatt
Member
# Posted: 16 Oct 2014 12:56
Reply


pine siding up on the interior


fitzpatt
Member
# Posted: 16 Oct 2014 12:58 - Edited by: fitzpatt
Reply


started the privy...


fitzpatt
Member
# Posted: 16 Oct 2014 12:59 - Edited by: fitzpatt
Reply


and finished it... Please let me know what you think


skootamattaschmidty
Member
# Posted: 16 Oct 2014 14:10
Reply


Looks great! Just need to cut a moon in the door!

mikehu1966
Member
# Posted: 16 Oct 2014 14:11
Reply


Looks Great, what are the dimensions?

skootamattaschmidty
Member
# Posted: 16 Oct 2014 14:11 - Edited by: skootamattaschmidty
Reply


Where abouts in Hastings highland are you? I'm in Addington Highlands

Wilbour
Member
# Posted: 16 Oct 2014 14:19 - Edited by: Wilbour
Reply


Fine workmanship! Looks like you did everything right.

You certainly like those screw brackets for footings!

Was going to ask how you made the ladder but there are plans for that on the Timbermart Cabin plan

Pookie129
Member
# Posted: 16 Oct 2014 15:33
Reply


Fitz. Awesome job - and group efforts. I'm in HH hood as well. Boulter area. Again great work ;) hope you and the family enjoy

fitzpatt
Member
# Posted: 16 Oct 2014 16:05
Reply


Thanks all. The bunkie is small at 9 * 12, but the loft allows for a very comfortable queen size mattress.

I do love those metal brackets. They allow you to easily level the structure if it settles against you.

For the ladder we simply used pine lumber and a circular saw to cut many notches for each rung to rest in, along with glue and screws. It is bolted to studs in the wall and pivots up against the wall when we want more room below.

We are located hastings highlands, near Maynooth.

fitzpatt
Member
# Posted: 16 Oct 2014 16:08 - Edited by: fitzpatt
Reply


This past weekend we were able to finally get the flooring put in. Turned out really well. My wife is thrilled. Trim is next...


neb
Member
# Posted: 19 Oct 2014 09:36
Reply


That looks great!! Nice job.
